Vision Sport Power Wheelchair with Power Seat Lift — 300 lb Capacity
Mid-wheel drive power wheelchair with powered seat lift. 20" turning radius. Built for riders up to 300 lbs. Batteries included.
The Vision Sport with Power Seat Lift is a mid-wheel drive power wheelchair with a powered seat elevator that raises you up to 7.5 inches -- high enough to reach counters, sit at a table, or look someone in the eye during a conversation. Built for riders up to 300 lbs, it delivers the tightest turning radius in our power chair lineup at just 20 inches.
Available in two lift configurations: 7.5" lift (16"-18" seat widths) or 6.5" lift (16"-20" seat widths) -- same price either way. The semi-reclining captain's seat adjusts up to 135 degrees, and the seat depth is customizable from 16" to 20" for a tailored fit.
U1 batteries and 4A off-board charger included. Ships ready to use.
KEY FEATURES
Power Seat Lift Raises up to 7.5" -- reach kitchen counters, dining tables, and shelves without assistance
20" Turning Radius The tightest turning radius in our lineup -- navigates tight hallways, small kitchens, and bathrooms with ease
Adjustable Seating 16" to 20" seat widths, 16" to 20" seat depth, captain or pan seat, semi-reclining backrest up to 135 degrees
300 lb Weight Capacity Standard-duty frame for average-weight riders
Batteries Included Two U1 batteries and 4A off-board charger ship with the chair -- nothing extra to buy
Seat Lift at a Lower Price Same powered seat lift technology as our heavy-duty Vision Super, for less
Specifications
| Specification | Detail |
|---|---|
| Model | P326D2 (7.5" lift) / P326D0 (6.5" lift) |
| Weight Capacity | 300 lbs |
| Drivetrain | Mid-Wheel Drive (MWD) |
| Seat Lift Height | 7.5" (P326D2) or 6.5" (P326D0) |
| Seat Width | 16" or 18" (7.5" lift) / 16", 18", or 20" (6.5" lift) |
| Seat Depth | 16" - 20" (customizable) |
| Seat Type | Captain or Pan |
| Backrest Height | 20" |
| Seat-to-Floor Height | 20.5" - 29.5" (with lift range) |
| Overall Length | 34" |
| Overall Width | 24" |
| Overall Height | 48.5" |
| Turning Radius | 20" |
| Ground Clearance | 2" |
| Total Weight | 214 lbs |
| Weight of Heaviest Piece | 120 lbs |
| Max Speed | 5 mph |
| Range Per Charge | Up to 18 miles |
| Motor | DC 24V / 160W |
| Controller | P&G VR2 60A |
| Batteries | 2x 35Ah, 12V, U1 (included) |
| Charger | 4A off-board (included) |
| Gradient / Hill Climb | 6 degrees |
| Front Wheels | 6" solid |
| Drive Wheels | 10" solid / foam-filled |
| Rear Wheels | 6" solid |
| Color Options | Red or Black (7.5" lift) / Red or Blue (6.5" lift) |
| HCPCS Codes | K0823 + K0108/E2300 (7.5" lift) / K0831 / K0830 (6.5" lift) |
| Manufacturer | Merits Health Products |
| Assembled | USA |
What's in the Box?
- Vision Sport power wheelchair base with mid-wheel drive
- Power seat lift mechanism (7.5" or 6.5" depending on configuration)
- Captain seat with armrests (or pan seat -- specify when ordering)
- 2x 35Ah U1 batteries (installed)
- 4A off-board charger
- Owner's manual
Choosing your Lift Height
The Vision Sport with Lift comes in two configurations at the same price:
7.5" Lift (Model P326D2) -- Greater lift range for maximum reach. Available in 16" or 18" seat widths. Choose this if reaching counters and high surfaces is your priority and you don't need a seat wider than 18".
6.5" Lift (Model P326D0) -- Slightly less lift range, but available in 16", 18", or 20" seat widths. Choose this if you need a 20" wide seat or if 6.5" of lift is sufficient for your needs.
Not sure which is right? Call us and we'll help you decide based on your height, reach goals, and seat width needs.
Vision Sport vs Vision Super - Which do I need?
We carry two power wheelchairs with seat lifts. Here's how to choose:
Choose the Vision Sport if you weigh under 300 lbs, want the tightest possible turning radius (20"), and want a seat lift at a lower price point.
Choose the Vision Super if you weigh between 300 and 400 lbs, need a heavier-duty frame, want 10" of seat lift (vs. 6.5"-7.5"), and need larger batteries for longer range (20 miles vs. 18 miles).
The core difference is weight capacity and lift height. Everything else -- mid-wheel drive, indoor maneuverability, captain or pan seat options -- is shared across both chairs.
Who is this For?
This chair is built for you if:
- You weigh up to 300 lbs and want a power wheelchair with a seat lift
- You primarily use the chair indoors and need to navigate tight spaces
- You want to reach kitchen counters, dining tables, and shelves independently
- You want the seat lift feature without paying for a heavy-duty frame you don't need
- You want batteries included with no extra parts to source
This may not be the right fit if:
- You weigh over 300 lbs (see our Vision Super with Lift -- 400 lb capacity, 10" lift)
- You weigh over 400 lbs and don't need a seat lift (see our Atlantis -- 600 lb capacity)
- You need a chair primarily for outdoor or rough terrain use (see our Silverado Extreme)
- You need a folding or portable chair for travel (see our Feather Power Chair at 33 lbs)
- You need extended range beyond 18 miles per charge
Delivery Information
Free shipping on this product. Delivered via freight carrier to your address.
Delivery includes liftgate service to lower the chair to ground level at your location. Residential delivery included.
White Glove Delivery available for $499 -- we bring it inside, unpack it, and set it up for you.
Estimated delivery: Ships from manufacturer. Delivery timeframe will be confirmed when you place your order.
Note: You will receive a call from the freight carrier to schedule your delivery window.
FAQ
Does this chair come with batteries? Yes. Two U1 batteries ship installed. The 4A off-board charger is also included.
What's the difference between the 7.5" and 6.5" lift? The 7.5" lift (P326D2) raises the seat one inch higher but is only available in 16" or 18" seat widths. The 6.5" lift (P326D0) offers a 20" seat width option. Same price either way. If you need a 20" wide seat, go with the 6.5" lift. If you need maximum height reach, go with the 7.5" lift.
How high does the seat go? With the 7.5" lift, the seat rises from approximately 20.5" to about 28"-29.5". That's high enough to sit at a standard dining table comfortably and reach most kitchen counters.
Can I use this chair outdoors? On flat, smooth surfaces like sidewalks and driveways, yes. The 6" solid casters and 2" ground clearance are designed for indoor and smooth surface use. For outdoor primary use, see our Silverado Extreme scooter.
How tight can it turn? 20" turning radius -- the tightest in our power wheelchair lineup. It can turn in spaces most other power chairs cannot.
How far does it go on one charge? Up to 18 miles under optimal conditions. Real-world range depends on rider weight, terrain, lift usage, and speed.
How much does it weigh? 214 lbs total. The heaviest single piece is 120 lbs.
What colors are available? The 7.5" lift model comes in Red or Black. The 6.5" lift model comes in Red or Blue. Confirm your preference when ordering.
What's the difference between captain and pan seat? Captain seat has built-in armrests and contoured shape -- most people choose this. Pan seat is a flat platform for custom cushions specified by a therapist. If you're unsure, go with captain.
Why is this cheaper than the Vision Super? The Vision Sport uses a standard-duty frame (300 lbs vs 400 lbs), smaller batteries (35Ah U1 vs 55Ah 22NF), and a smaller motor (160W vs 300W). If you weigh under 300 lbs, you get the same seat lift functionality at a lower price without paying for heavy-duty capacity you don't need.
What if it needs service or repair? As an authorized Merits dealer, we can help coordinate warranty service and replacement parts. Contact us and we'll handle it.
About the Manufacturer
Medical Mobility Supply is an authorized Merits dealer.
